1000BASE-tx Discrete Magnetic Transformer HST-24001SCR / HST-24001SXCR

Product Description

Magnetic Transformer Overview
1000BASE-tx Discrete Magnetic Transformer HST-24001SCR / HST-24001SXCR
Products Description
ItemLan Transformer
Replaceable ModelHST-24001SCR / HST-24001SXCR
Part StatusActive
ConstructionOpen Frame
Number of Positions8p8c (RJ45, Ethernet)
Application-LanEthernet (Non PoE)
Number of Ports1 Port
Speed1000 Base-t
Cores per Port8
Pin Number24 Pin
Mounting TypeSMT
Temperature0℃ TO 70℃
AutoMDIXYES
Turns Ratio RX/TX1CT:1CT
Configuration RX/TXT,C,S
PackageTape & Reel
Technical Drawing 1
Technical Drawing 2
Why Choose Us
Company Profile
We are a specialized manufacturer of magnetic telecom and networking components, certificated by ISO9001:2000, ROSH, REACH, CE and UL. We own advanced manufacturing facilities and test equipment imported from abroad. Established in 1997, we have around 2000 staff at present. With an abundant productive capacity of 3000K per month, we are able to deliver goods within a short time. Moreover, we provide professional complete solutions for magnetic components and strong technical support.

Main Products: 10/100/1000M LAN pulse transformer and filter, RJ45 connector with 10/100/1000M magnetic, T1/E1, T3/DS3/E3/STS-1 interface line transformer, ISDN, HDSL, ADSL and VDSL interface line transformer and splitter. Our products are widely used in networking and communication equipment such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, and xDSL modem.

Our engineering staff is dedicated to identifying, developing, and manufacturing the optimal solution for unique requirements. We trust our strength in the field and our faith in pursuing higher standards will convince you to be our long-term partner.
FAQ
Are you a factory or trading company?
We are a specialized manufacturer of magnetic telecom and networking components, such as RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
Can I get a sample before mass production?
Yes, we can offer you free samples to test quality, but shipping fees apply.
What is your delivery time?
Ready to ship for stock items and 15-30 days for mass production.
What after-service can you offer?
One year guarantee period and technical support online 24 hours.
Can you accept OEM/ODM orders?
Yes, please send an inquiry to us so that we can have a detailed discussion.
What is your advantage?
Over 19 years of production experience and long-term partnerships with major industry leaders.
