| Tyco Part Number |
1116173-4 |
| LINK-PP Part Number |
LPJE101AHNL |
| Application-LAN |
ETHERNET(NON POE) |
| AutomDX |
YES |
| Package Height (Inches/mm) |
0.516/13.10 |
| Package Length (Inches/mm) |
0.620/15.75 |
| Package Width (Inches/mm) |
0.640/16.26 |
| Configuration TX/RX |
T,C |
| Contact Mating Area Plating |
GOLD 6u"/15u"/30u" |
| Cores Per Port |
- |
| Diodes |
No |
| Latch |
Up |
| LED Option |
Green/Yellow LEDS |
| Number of Ports |
1X1 |
| PCB Mount Angle |
SIDE ENTRY |
| PCB Retaining Post |
T POST |
| Pin Type |
THT SOLDER |
| RoHS Compliant |
YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Search |
YES |
| Shield EMI Tabs |
WITH |
| Speed |
- |
| Temperature |
-40 TO 85°C |
| Turns Ratio RX |
1CT:1 |
| Turns Ratio TX |
1CT:1 |
Why Choose Us
World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers
Professional Certification
- ISO 9001:2008
- UL Certification
- Reach Certification
- RoHS Compliance
- Active Environmental Policy
100% Guarantee Quality
- Manufactured Under Strict Controls.
- 100% Tested (Not Just Batch Tested)
- OEM of TE (Tyco) for 9 Years
- Successful Customer: Texas Instruments, Samsung, Cisco, Siemens, and Intel...
- Preferred Supplier of TI (Texas Instruments)
- Quality Guarantee: 6 Years
Competitive Price And Service
- More Competitive Price Than Pulse, Tyco, Halo, Wurth, and Amphenol
- Delivery Time: 2-3 Weeks After Orders
- Free Samples Are Available
- Provide New Design For Customer Requirements
- 90% Off Shipping Cost By DHL, UPS, FEDEX, Or TNT
Corporate Policy
- The Corporate Goal Is To Achieve The Highest Level Of Customer Satisfaction Through Continuous Improvements In Quality, Delivery And Service
- Committed To And Expects Quality Performance From Every Employee
- The Company Standard Is Defect-Free Products And Services
Preferred Supplier Of TI Samsung Cisco Siemens ...
Welcome To Visit The TI Website to view BeagleBone Board details
You Will Look At Our Logo "LINK-PP" On BeagleBone Board
Frequently Asked Questions
What is the cross-reference part number for the 1116173-4 RJ45 connector?
The equivalent part number is LPJE101AHNL. It matches the original specifications for standard networking applications.
Does this RJ45 Modular Jack support Power over Ethernet (PoE)?
No, this specific part number is designed for non-PoE Ethernet applications as listed in the technical specifications.
What type of LEDs are integrated into this RJ45 connector?
This modular jack features integrated Green and Yellow LEDs (W/Y LED configuration) for status indication.
What is the operating temperature range for this part?
It is designed to operate reliably within a temperature range of -40°C to 85°C, making it suitable for industrial environments.
What mounting and pin styles does this RJ45 modular jack use?
It features a Through-Hole Technology (THT) solder pin type with a side entry (right angle) PCB mounting layout.
Is this RJ45 modular jack RoHS compliant?
Yes, it is RoHS compliant with lead-in-solder exemption (RoHS-5).
