Dorelink
Dorelink
| Item | Fiber Optical Modules |
| Part Status | Active |
| Form Factor | QSFP28 |
| Max Data Rate | 103.125G |
| Max Cable Distance | 40km |
| Wavelength | 1310nm |
| Connector | Duplex LC |
| Media | SMF |
| Optical Component | EML/APD |
| TX Power | -2.9~4.5dBm |
| Minimum Receiver Power | -20.9dBm |
| Powerbudget | 18dB |
| Receiver Overload | -4.9dBm |
| Power Consumption | ≤4.5W |
| Extinction Ratio | ＞4dB |
| DDM/DOM | DDM Supported |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Warranty | 5 Years |
| Sample | Available |
| Protocols | QSFP28 MSA Compliant |
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, ROSH, REACH, CE, and UL. Our facility owns advanced manufacturing facilities and test equipment imported from abroad.
Established in 1997, we currently have around 2000 staff. With an abundant productive capacity of 3000K per month, we are able to deliver products within a short time.
Moreover, we provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks. The range also offers high-speed optical interconnection solutions for cloud computing and ultra-broadband networks.
