| Item | 2.5G SFP |
| Part Status | Active |
| Form Factor | SFP |
| Max Data Rate | 2.5Gbps |
| Wavelength | 850nm |
| Max Cable Distance | 300m |
| Media | MMF |
| Connector | Duplex LC |
| Optical Component | VCSEL/PIN |
| TX Power | -10~-3dBm |
| Receiver Sensitivity | <-18dBm |
| Receiver Overload | -3dBm |
| Power Consumption | 1W |
| Extinction Ratio | >8.2dB |
| DDM/DOM | Supported |
| Temperature Range | -10 to 70°C (-37 to 158°F) |
| Protocols | SFP MSA(INF-8074i), GR-253-CORE, ITU-T G.957, FC-PI v2.0, SFF-8472 v9.5 |
| Warranty | 5 Years |
We are a specialized manufacturer of magnetic telecom and networking components, certificated by ISO9001, ROSH, REACH, CE and UL. Our facilities own advanced manufacturing and test equipment to ensure the highest quality standards. With an abundant productive capacity of 3000K per month, we are able to deliver goods within short lead times.
Main Products:
Our products are widely used in networking and communication equipment such as HUBs, PC cards, Switches, Routers, IP Phones, and xDSL modems. We have exported products to more than 30 countries and regions worldwide.
